AVAILABLE SYSTEMS
ST – STANDARD – tests entered manually
AT – AUTOTEST – internal components, battery and light source tests are performed automatically
CT – CENTRALTEST – internal component, battery and light source tests performed on command from the H-300 central control system main unit
CB – luminaire powered from HVCBS (230V AC/ 216V DC), without address module
CBAM – luminaire powered from HVCBS (230V AC/ 216V DC), with built-in address module and operating mode selection
LVAM – luminaire powered by 24V DC from the LVDBS system, with built-in address module and operating mode selection
MATERIAL
Housing material – powder-coated aluminum
Cabinet colors – q RAL 9003, q RAL 9006, q RAL 9005 – others by special order
Shade material – PC
CHARACTERISTICS OF LUMINAIRE:
- the light shows the direction of the leak
- LED indicators indicating the status of the lamp
- protection against deep battery discharge
- maintained/unmaintained operating mode
- the possibility of connecting to a common power supply system
- wall mounting
- the housing is made of aluminum
- installation inside the building
- two size variants
- the diffuser is made of PC
